Angel Dur

Mae dur ongl, a elwir yn gyffredin fel haearn ongl yn y diwydiant, yn stribed hir o ddur gyda dwy ochr ar ongl sgwâr. Mae'r deunydd fel arfer yn ddur strwythurol carbon cyffredin a dur aloi isel.

Anfon ymchwiliad

Cyflwyniad Cynnyrch

Maint a Dimensiynau

Maint a Dimensiynau	Wgt. Per Ft.
1/2 x 1/2 x 1/8	0.38
3/4 x 3/4 x 1/8	0.59
1 x 1 x 1/8	0.80
1 x 1 x 3/16	1.16
1 x 1 x 1/4	1.49
1 1/4 x 1 1/4 x 1/8	1.01
1 1/4 x 1 1/4 x 3/16	1.48
1 1/4 x 1 1/4 x 1/4	1.92
1 1/2 x 1 1/2 x 1/8	1.23
1 1/2 x 1 1/2 x 3/16	1.80
1 1/2 x 1 1/2 x 1/4	2.34
1 3/4 x 1 3/4 x 1/8	1.44
1 3/4 x 1 3/4 x 3/16	2.12
1 3/4 x 1 3/4 x 1/4	2.77
2 x 1 1/2 x 1/8	1.44
2 x 1 1/2 x 3/16	2.12
2 x 1 1/2 x 1/4	2.77
2 x 2 x 1/8	1.65
2 x 2 x 3/16	2.44
2 x 2 x 1/4	3.19
2 x 2 x 5/16	3.92
2 x 2 x 3/8	4.70
2 1/2 x 1 1/2 x 3/16	2.44
2 1/2 x 1 1/2 x 1/4	3.19
2 1/2 x 1 1/2 x 5/16	3.92
2 1/2 x 2 x 3/16	2.75
2 1/2 x 2 x 1/4	3.62
2 1/2 x 2 x 5/16	4.50
2 1/2 x 2 x 3/8	5.30
2 1/2 x 2 1/2 x 3/16	3.07
2 1/2 x 2 1/2 x 1/4	4.10
2 1/2 x 2 1/2 x 5/16	5.00
2 1/2 x 2 1/2 x 3/8	5.90
2 1/2 x 2 1/2 x 1/2	7.70
3 x 2 x 3/16	3.07
3 x 2 x 1/4	4.10
3 x 2 x 5/16	5.00
3 x 2 x 3/8	5.90
3 x 2 x 1/2	7.70
3 x 2 1/2 x 3/16	3.39
3 x 2 1/2 x 1/4	4.50
3 x 2 1/2 x 5/16	5.60
3 x 2 1/2 x 3/8	6.60
3 x 2 1/2 x 1/2	8.50
3 x 3 x 3/16	3.70
3 x 3 x 1/4	4.90
3 x 3 x 3/8	7.20
3 x 3 x 1/2	9.40
3 1/2 x 3 x 1/4	5.40
3 1/2 x 3 x 5/16	6.60
3 1/2 x 3 x 3/8	7.90
3 1/2 x 3 x 1/2	10.20
3 1/2 x 3 1/2 x 1/4	5.80
3 1/2 x 3 1/2 x 5/16	7.20
3 1/2 x 3 1/2 x 3/8	8.50
3 1/2 x 3 1/2 x 1/2	11.10
4 x 3 x 1/4	5.80
4 x 3 x 5/16	7.20
4 x 3 x 3/8	8.50
4 x 3 x 1/2	11.10
4 x 3 1/2 x 1/4	6.20
4 x 3 1/2 x 5/16	7.70
4 x 3 1/2 x 3/8	9.10
4 x 3 1/2 x 1/2	11.90
4 x 4 x 1/4	6.60
4 x 4 x 5/16	8.20
4 x 4 x 3/8	9.80
4 x 4 x 1/2	12.80
4 x 4 x 5/8	15.70
4 x 4 x 3/4	18.50
5 x 3 x 1/4	6.60
5 x 3 x 5/16	8.20
5 x 3 x 3/8	9.80
5 x 3 x 3/8	12.80
5 x 3 x 5/8	15.70
5 x 3 x 3/4	18.50
5 x 3 1/2 x 1/4	7.00
5 x 3 1/2 x 5/16	8.70
5 x 3 1/2 x 3/8	10.40
5 x 3 1/2 x 1/2	13.60
5 x 3 1/2 x 5/8	16.80
5 x 3 1/2 x 3/4	19.80
5 x 5 x 5/16	19.80
5 x 5 x 3/8	12.30
5 x 5 x 1/2	16.20
5 x 5 x 5/8	20.00
5 x 5 x 3/4	23.60
5 x 5 x 7/8	27.20
6 x 3 1/2 x 5/16	9.80
6 x 3 1/2 x 3/8	11.70
6 x 3 1/2 x 1/2	15.30
6 x 3 1/2 x 5/8	18.80
6 x 4 x 5/16	10.30
6 x 4 x 3/8	12.30
6 x 4 x 1/2	16.20
6 x 4 x 5/8	20.00
6 x 4 x 3/4	23.60
6 x 6 x 5/16	12.50
6 x 6 x 3/8	14.90
6 x 6 x 1/2	19.60
6 x 6 x 5/8	24.20
6 x 6 x 3/4	28.70
6 x 6 x 7/8	33.10
6 x 6 x 1	37.40
7 x 4 x 3/8	13.60
7 x 4 x 1/2	17.90
7 x 4 x 3/4	26.20
8 x 4 x 1/2	19.60
8 x 4 x 5/8	24.20
8 x 4 x 3/4	28.70
8 x 4 x 1	37.40
8 x 6 x 1/2	23.00
8 x 6 x 5/8	28.50
8 x 6 x 3/4	33.80
8 x 6 x 1	44.20
8 x 8 x 1/2	26.40
8 x 8 x 5/8	32.70
8 x 8 x 3/4	38.90
8 x 8 x 7/8	45.00
8 x 8 x 1	51.00
8 x 8 x 1 1/8	56.90
9 x 4 x 1/2	21.30
9 x 4 x 5/8	26.30
9 x 4 x 3/4	31.30

Disgrifiad Cynnyrch

Ongl durGall fod yn cynnwys gwahanol gydrannau straen yn unol â gwahanol anghenion y strwythur, a gellir ei ddefnyddio hefyd fel cysylltydd rhwng rhannau, a ddefnyddir yn helaeth mewn amrywiol strwythurau adeiladu a strwythurau peirianneg, megis trawstiau, pontydd, tyrau trawsyrru, peiriannau codi a chludo , llongau, ffwrneisi diwydiannol, tyrau adweithio, raciau cynwysyddion, cynheiliaid ffosydd cebl, pibellau pŵer, gosod cymorth bar bysiau, silffoedd warysau, ac ati.
